Technical details
Operating Manual PNOZ s30
1001715-EN-13
68
Incremental encoder input 750330 751330
Signal level at the inputs 0,5 - 30,0 Vss 0,5 - 30,0 Vss
Phase position for the differential
signals A, /A and B,/B
90° ±30° 90° ±30°
Overload protection -50 - 65 V -50 - 65 V
Input resistance 20,0 kOhm 20,0 kOhm
Input's frequency range 0 - 1.000 kHz 0 - 1.000 kHz
Configurable monitoring frequency
Without hysteresis 10 mHz - 1.000 kHz 10 mHz - 1.000 kHz
Semiconductor outputs 750330 751330
Number 4 4
Voltage 24,0 V 24,0 V
Current 50 mA 50 mA
Relay outputs 750330 751330
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
Auxiliary contacts, AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 4,0 A 4,0 A
Max. power 1000 VA 1000 VA
Auxiliary contacts, DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 4,0 A 4,0 A
Max. power 100 W 100 W
Safety contacts, AC1 at 240 V 240 V
Max. current 4,0 A 4,0 A
Min. current 0,01 A 0,01 A
Max. power 1000 VA 1000 VA
Safety contacts, DC1 at 24 V 24 V
Max. current 4,0 A 4,0 A
Min. current 0,01 A 0,01 A
Max. power 100 W 100 W
Utilisation category
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Auxiliary contacts, AC15 at 230 V 230 V
Max. current 3,0 A 3,0 A
Auxiliary contacts, DC13 (6 cy-
cles/min) at
24 V 24 V
Max. current 4,0 A 4,0 A
Safety contacts, AC15 at 230 V 230 V
Max. current 3,0 A 3,0 A
Safety contacts, DC13 (6 cycles/
min) at
24 V 24 V
Max. current 4,0 A 4,0 A
