Function description
Operating Manual PNOZ s30
1001715-EN-13
22
Parameter set
Signal states of the select inputs
SEL 8 (Y13) SEL 4 (Y12) SEL 2 (Y11) SEL 1 (Y10)
P1
0
0
0
1
P2
0
0
1
0
P4
0
1
0
0
P8
1
0
0
0
When using these 4 parameter sets, the following safety features are met:
If there is an error when activating the select inputs, such as
}
Short circuits and shorts between contacts
}
Open circuit
}
Input drift
a parameter set other than P1, P2, P4 or P8 is selected.
The lowest frequency (10 mHz) is automatically set for the other parameter sets (P0, P3,
P5 ... P7, P9 ... P15). If one of these parameter sets is selected, an error message appears
and all outputs switch off.
"All 16" mode
In this mode, the number of parameter sets can be increased to max. 16. This mode can
only be used for applications up to max. PL d of EN ISO 13849-1 and up to SIL CL 2 of
EN IEC 62061.
Parameter set
Signal states of the select inputs
SEL 8 (Y13) SEL 4 (Y12) SEL 2 (Y11) SEL 1 (Y10)
P0
0
0
0
0
P1
0
0
0
1
P2
0
0
1
0
P3
0
0
1
1
P4
0
1
0
0
P5
0
1
0
1
P6
0
1
1
0
P7
0
1
1
1
P8
1
0
0
0
P9
1
0
0
1
P10
1
0
1
0
P11
1
0
1
1
P12
1
1
0
0
P13
1
1
0
1
P14
1
1
1
0
P15
1
1
1
1
