Fabric OS Administrator’s Guide
53-1001763-02
Port indexing on the Brocade DCX-4S backbone
C
TABLE 101
Default index/16-bit PID assignment with no port swap for the Brocade DCX-4S
Port on blade
Slot 1 Index/PID Slot 2 Index/PID Slot 7 Index/PID Slot 8 Index/PID
63
63/0x3f00
127/0x7f00
191/0xbf00
255/0xff00
62
62/0x3e00
126/0x7e00
190/0xbe00
254/0xfe00
61
61/0x3d00
125/0x7d00
189/0xbd00
253/0xfd00
60
60/0x3c00
124/0x7c00
188/0xbc00
252/0xfc00
59
59/0x3b00
123/0x7b00
187/0xbb00
251/0xfb00
58
58/0x3a00
122/0x7a00
186/0xba00
250/0xfa00
57
57/0x3900
121/0x7900
185/0xb900
249/0xf900
56
56/0x3800
120/0x7800
184/0xb800
248/0xf800
55
55/0x3700
119/0x7700
183/0xb700
247/0xf700
54
54/0x3600
118/0x7600
182/0xb600
246/0xf600
53
53/0x3500
117/0x7500
181/0xb500
245/0xf500
52
52/0x3400
116/0x7400
180/0xb400
244/0xf400
51
51/0x3300
115/0x7300
179/0xb300
243/0xf300
50
50/0x3200
114/0x7200
178/0xb200
242/0xf200
49
49/0x3100
113/0x7100
177/0xb100
241/0xf100
48
48/0x3000
112/0x7000
176/0xb000
240/0xf000
47
47/0x2f00
111/0x6f00
175/0xaf00
239/0xef00
46
46/0x2e00
110/0x6e00
174/0xae00
238/0xee00
45
45/0x2d00
109/0x6d00
173/0xad00
237/0xed00
44
44/0x2c00
108/0x6c00
172/0xac00
236/0xec00
43
43/0x2b00
107/0x6b00
171/0xab00
235/0xeb00
42
42/0x2a00
106/0x6a00
170/0xaa00
234/0xea00
41
41/0x2900
105/0x6900
169/0xa900
233/0xe900
40
40/0x2800
104/0x6800
168/0xa800
232/0xe800
39
39/0x2700
103/0x6700
167/0xa700
231/0xe700
38
38/0x2600
102/0x6600
166/0xa600
230/0xe600
37
37/0x2500
101/0x6500
165/0xa500
229/0xe500
36
36/0x2400
100/0x6400
164/0xa400
228/0xe400
35
35/0x2300
99/0x6300
163/0xa300
227/0xe300
34
34/0x2200
98/0x6200
162/0xa200
226/0xe200
33
33/0x2100
97/0x6100
161/0xa100
225/0xe100
32
32/0x2000
96/0x6000
160/0xa000
224/0xe000
31
31/0x1f00
95/0x5f00
159/0x9f00
223/0xdf00
30
30/0x1e00
94/0x5e00
158/0x9e00
222/0xde00
29
29/0x1d00
93/0x5d00
157/0x9d00
221/0xdd00
