Page 402
362
Fabric OS Administrator’s Guide
53-1001763-02
SAN management with Admin Domains
15
Admin Domains and LSAN zones
LSANs under each Admin Domain are collated into a single name space and sent out to FCR
phantom domains using the following format:
<original_LSAN_name>_AD<AD_num>
For example, a zone with name lsan_for_linux_farm in AD5 is internally converted to
lsan_for_linux_farm_AD005.
LSAN zone names in AD0 are never converted for backward compatibility reasons.
The auto-converted LSAN zone names might collide with LSAN zone names in AD0 (for example, in
the above example, if AD0 contains lsan_for_linux_farm_AD005, this causes a name collision).
Fabric OS does not detect or report such name clashes.
LSAN zone names greater than 57 characters are not converted or sent to the FCR phantom
domain. See
Chapter 21, “Using the FC-FC Routing Service,”
for information about LSAN zones.
Configuration upload and download in an AD context
The behavior of the configUpload and configDownload commands varies depending on the AD
context and whether the switch is a member of the current Admin Domain. In the AD context, these
commands include only the zone configuration of the current Admin Domain. If the switch is a
member of the Admin Domain, all switch configuration parameters are saved and the zone
database for that Admin Domain is also saved.
lists the sections in the configuration file and the Admin Domain contexts in which you can
upload and download these sections. See
Chapter 8, “Maintaining the Switch Configuration File,”
for additional information about uploading and downloading configurations.
NOTE
You cannot use configDownload to restore a single Admin Domain. To restore a single Admin
Domain, you must first delete all Admin Domains and then issue configDownload to restore them.
The configDefault command does not clear zone or Admin Domain database information. This
command is allowed only if the switch is a member of the current Admin Domain.
TABLE 76
Configuration upload and download scenarios in an AD context
Configuration file sections
AD contexts
iSCSI
ACL
Zone
AD headers
Switch configuration
and other parameters
AD255: With ADs
Yes
Yes
Yes
1
1.
Zone databases for AD0 through AD254.
Yes
Yes
Without ADs
Yes
Yes
Yes
Yes
Yes
AD0:
With ADs and switch membership
Yes
No
Yes
2
2.
Only zone database for AD0.
No
Yes
With ADs and without switch membership
Yes
No
Yes
No
No
Without ADs
Yes
Yes
Yes
No
Yes
AD1 – AD254: With switch membership
No
No
Yes
3
3.
Only zone database for current AD.
No
Yes
Without switch membership
No
No
Yes
No
No
