Processor

Dell™ OptiPlex™ GX280 Systems User's Guide

Removing the Processor

CAUTION:

Before you begin any of the procedures in this section, follow the safety instructions located in

the Product Information Guide.

CAUTION:

To prevent static damage to components inside your computer, discharge static electricity from

your body before you touch any of your computer's electronic components. You can do so by touching an

unpainted metal surface on the computer chassis.

Removing the Processor

1. Follow the procedures in "

2. Disconnect the cooling fan power cable from the FAN connector on the

3. Disconnect the power cable from the 12VPOWER connector on the

4. Lift up the airflow shroud.

CAUTION:

The heat sink can get very hot during normal operation. Be sure that the heat sink has had

sufficient time to cool before you touch it.

5. Remove the heat sink:
