Dell OptiPlex GX280 User Manual

Page 300

1 drive
2 bracket rails (2)
3 screws (4)

2. Gently slide the drive into place until you hear a click or feel the drive securely installed.

3. Attach the power and floppy-drive cables to the floppy drive.

4. Connect the other end of the floppy-drive cable to the connector labeled "DSKT" on the

1 power cable
2 floppy-drive cable
3 floppy-drive connector (DSKT)

5. If you are installing a new floppy drive rather than replacing a drive,

6. Check all cable connections, and fold cables out of the way to provide airflow for the fan and cooling vents.

7. Close the computer cover.

NOTICE:

To connect a network cable, first plug the cable in to the network wall jack and then plug it in to the
