1 GB Port
2 STK Port
CMC Port Information
The following TCP/IP ports are required to remotely access CMC through firewalls. These are the ports CMC listens to
for connections.
Table 1. CMC Server Listening Ports
Port Number Function
22* SSH
23* Telnet
80* HTTP
161 SNMP Agent
443* HTTPS
* Configurable port
The following table lists the ports that CMC uses as a client.
Table 2. CMC Client Port
Port Number Function
25 SMTP
53 DNS
68 DHCP-assigned IP address
69 TFTP
162 SNMP trap
514* Remote syslog
636 LDAPS
3269 LDAPS for global catalog (GC)
* Configurable port
Minimum CMC Version
The following table lists the minimum CMC version required to enable the listed Blade Servers.
Table 3. Minimum CMC Version for Blade Servers
Servers Minimum version of CMC
PowerEdge M600 CMC 1.0
PowerEdge M605 CMC 1.0
PowerEdge M805 CMC 1.2
18
