NOTE: The FTOS or IOM software version is displayed in the format X-Y(A-B). For example, 8-3(1-4). If the
Rollback Version of the FTOS image is an old image which uses the old version string format 8-3-1-4, then the
Current Version is displayed as 8-3(1-4).
Managing VLAN for IOM
Virtual LANs (VLANs) for IOMs allow you to separate users into individual network segments for security and other
reasons. By using VLANs you can isolate the networks for individual users on a 32 port switch. You can associate
selected ports on a switch with selected VLAN and treat these ports as a separate switch.
CMC Web Interface allows you to configure the in-band management ports (VLAN) on the IOMs.
Related Links
Configuring VLAN settings on IOMs Using CMC Web Interface
Viewing the VLAN settings on IOMs Using CMC Web Interface
Viewing the Current VLAN Settings on IOMs Using CMC Web Interface
Adding Tagged VLANs for IOMs Using CMC Web Interface
Removing VLANs for IOMs Using CMC Web Interface
Updating Untagged VLANs for IOMs Using CMC Web Interface
Resetting VLANs for IOMs Using CMC Web Interface
Configuring Management VLAN on IOMs Using Web Interface
You can manage the IO Aggregator in-band through a VLAN. This VLAN must be deployed prior to use. CMC allows in-
band management VLAN deployment. The switch’s in-band management VLAN requires the following basic
configuration of settings to be applied:
• Enable
• VLAN ID
• Priority
NOTE:
Configuring the management VLAN on the Vlan Settings page requires Chassis Configuration privileges. This privilege is
also required for IOM VLAN configuration, in addition to the Administrator privileges to the specific fabric A, B, or C.
To configure Management VLAN for IOMs using the CMC Web interface:
1. In the system tree, go to Chassis Overview and click Network → VLAN
The VLAN Tag Settings page is displayed.
2. In the I/O Modules section, enable VLAN for the IOMs, set the priority and enter the ID. For more information about
the fields, see the CMC Online Help .
3. Click Apply to save the settings.
Configuring Management VLAN on IOMs Using RACADM
To configure management VLAN on IOMs using RACADM, use the racadm setniccfg –m switch-n -v
command.
• Specify the VLAN ID and priority of a particular IOM with the following command:
racadm setniccfg -m switch - -v
The valid values for are 1 – 6.
The valid values for are 1 – 4000 and 4021 – 4094. Default is 1.
