JP1 Ribbon Cable Coin Acceptor Interface
Pin
Description
1
12VDC switched (500 mA average max)
2
GND for 12VDC
3
Coin 4 (sink to pin 2 for coin input)
4
Coin 3 (sink to pin 2 for coin input)
5 N/C
6 N/C
7
Coin 2 (sink to pin 2 for coin input)
8 N/C
9
Coin 1 (sink to pin 2 for coin input)
10 N/C
11 N/C
12 N/C
13 N/C
14 N/C
15 N/C
16
GND for 12VDC
J25 Diverter Solenoid Output
Pin
Description
1
12VDC + solenoid fire output
2
Ground 12VDC for solenoid output
3 N/C
