W A S H S E L E C T I I
Document Number: WS21058 56
Document Title: WSII Operations Manual ver 6.10
4.5 Multi-Coin Acceptor Programming and Operation
This optional item allows the Wash Select II to accept U.S. quarters, dollar coins and up to
four different bi-metal tokens. The Wash Select II accepts tokens ranging in size from .984” –
1.125” in diameter.
The current configuration of the Wash Select II only allows one coin to be dispensed at a
time. Therefore, if you would like to dispense the dollar coin, it will be necessary to make
changes to the coin hopper.
4.5.1 Programming the IDX Acceptor
Note: When inserting coins into the IDX, you must be sure to close the cover completely.
The unit comes equipped to accept both U.S. quarters and dollar coins, and will dispense
quarters by default. The unit will also accept site-specific tokens. This section will guide you
through the programming of each of the site-specific coins that will be accepted and give
details on erasing this program, if a programming error ever occurs.
In order to complete the programming you must have six of each of the tokens and coins you
wish to accept. It is very important that you follow these directions exactly. The IDX acceptor
will average the variances in these different sample coins during programming, and calculate
a more accurate reference model. Using less than six different coins will invalidate the
average variance generated by this process.
Please refer to the block diagrams shown in Figure 13 while programming the IDX coin
acceptor.
