W A S H S E L E C T I I
Document Number: WS21058 80
Document Title: WSII Operations Manual ver 6.10
J19 Fault/Warning Outputs
Pin Description
1 Fault output Common (dry contact) 500ma max
2 Fault output Normally Open (dry contact) 500 ma max
3 Warning output Common (dry contact) 500 ma max
4 Warning output Normally Open (dry contact) 500ma max
J18 Wash Inputs
Pin Description
1 Wash In Use Hot (20-120VAC/DC)
2 Wash In Use Neutral
3 Wash Fault Hot (20-120VAC/DC)
4 Wash Fault Neutral
5 Wash Warning Hot (20-120VAC/DC)
6 Wash Warning Neutral
J17 Wash Relays
Pin Description
1 Program relay 1 output (500mA max)
2 Program relay 2 output (500mA max)
3 Program relay 3 output (500mA max)
4 Program relay 4 output (500mA max)
5 Program relay 5 output (500mA max)
6 Program relay 6 output (500mA max)
7 Program relay 7 output (500mA max)
8 Program relay 8 output (500mA max)
9 Program relay Common
10 N/C
