W A S H S E L E C T I I
Document Number: WS21058 53
4 . 3 . 1 . 6 C l e a n i n g a n d G e n e r a l M a i n t e n a n c e
The AE2600 series will not need cleaning as often as magnetic sensing bill validators. If
cleaning is required, use a soft cloth moistened with mild, non-abrasive detergent.
4 . 3 . 1 . 7 P r o g r a m m i n g t h e M a r s B i l l V a l i d a t o r
The Mars Bill Validator allows programming for a maximum-security setting, as well as a
setting for a specified direction that a bill can be inserted. These options are set by a DIP
switch package located on one side of the validator.
To change any of the options, perform the following steps.
1. Remove the Mars Bill Validator from the unit. (See Section 4.3.1.2 for
instructions.)
2. Referring to Table 10, use a small flat-head screwdriver to set the DIP switches
for the options you prefer. (See Figure 12 for DIP switch location.)
DIP switches
Figure 12. Mars DIP Switches
Table 10. Mars Bill Validator DIP Switches
Switch ON OFF Default
