7.4 Analysis Tools
Analysis tools analyze the information gathered with the Vision tools to create measurements and tolerances
for the Vision tools.
Analysis Tools
BCR/BCR
1.3 GEO/GEO
1.3 EDGE/EDGE
1.3 AREA/AREA1.3 OMNI/OMNI
1.3 OMNI
Color ProII/ProII
1.3 ProII
Color Location
Tools
No No No No Yes Yes Yes Yes Coordinate
Tool7.4.2
Coordinate
Tool
on
page 178
Yes Yes Yes Yes Yes Yes Yes Yes Communication
Tool7.4.1
Communication
Tool
on
page 161
Yes Yes Yes Yes Yes Yes Yes Yes Math
Tool7.4.3
Math Tool
on page
181
Yes Yes Yes Yes Yes Yes Yes Yes Measure
Tool7.4.4
Measure
Tool
on
page 186
Yes No No No Yes Yes Yes Yes String
Tool7.4.5
String Tool
on page
207
Yes Yes Yes Yes Yes Yes Yes Yes Test
Tool7.4.6
Test Tool
on page
214
7.4.1 Communication Tool
The Communication tool is used to conditionally export data from the Sensor to an external device. Results
from Vision tools can be selected by the Communication tool and exported to an external device. The Sensor
can export data over the Ethernet or via its serial channels.
Examples of exported results
