One-Shot
Once an ROI has been defined and terminated, the software performs a one-shot analysis of the existing
image. The software sends the values of all the input parameters to the sensor where the sensor performs
analysis on the reference image with those values, and computes initial values for number of good, narrow,
and wide regions as well as other characteristics of the regions.
Bead Tool Inputs
Bead Type
From the drop-down list, select Dark Bead or Bright Bead as appropriate for your application.
Threshold
Type
Adaptive
Select Adaptive when there are lighting changes that cause the acquired image to change.
