6.6 Metrohm solvent delivery unit
IC Net 2.0 73
%D
Individual flow rate for pump D in percent of
total flow.
Entry range: 0 ... 100 %
Enabled
Enable time program start (a disabled pro-
gram is not started).
Show flow column
Show
Flow
column in the program table.
Add a new line to the time program.
Delete the selected line from the time pro-
gram.
Start all pump drives.
Interfaces
The Interfaces tab of the SDU window is only available for a con-
nected system.
Number of eluents Number of eluents used for gradient mix-
ing.
Pumps List of used pumps for gradient mixing.
Clicking on , , , or opens the
709 IC Pump window for parameter settings
and manual control of the selected pump.
Pressure checking Selection of the pump whose pressure is
checked using the Min/Max pressure limits.
Links
The
Links
tab of the
Metrohm SDU
is used for COM port selection
and settings (details see section 5.2.4).
