5 Interfaces
IC Net 2.0 40
Handshake
Enable/disable software handshake mode.
Selection: Swchar , none
Default value: SWchar
Read current parameters from 771 Com-
pact Interface.
Send current parameters to 771 Compact
Interface.
Links
The Links tab of the 771 IC Interface is used for COM port selection
and settings (details see section 5.2.4).
5.4 761 Compact IC
5.4.1 761 Compact IC features
The Metrohm 761 Compact IC is a PC-controlled system for ion
chromatographic analyses. The two following versions are avail-
able:
• 2.761.0010 Compact IC without suppressor module
• • 2.761.0020 Compact IC with suppressor module
All the parts of the 761 Compact IC like injection valve, high-
pressure pump, conductivity detector, suppressor module and
peristaltic pump, are normally fully controlled by the «761 Com-
pact IC» program. However, the 761 Compact IC can also be
operated using the «IC Net» program. This program also enables
the operation of more than one 761 Compact IC with one PC.
The 761 Compact IC is normally connected to a PC COM port
using the 6.2134.100 connecting cable.
For detailed information about the 761 Compact IC see 761 In-
structions for Use.
5.4.2 761 icon on the toolbar
The 761 icon is available on the toolbar if a 761 Compact IC has
been installed with the new system wizard or by using the
device> option of the WORKPLACE window (see section 5.1.2). By
clicking this icon the 761 Compact IC window for parameter set-
tings opens.
