8 Chromatograms
IC Net 2.0 150
8.3 Graphical representation
8.3.1 Appearance
IC NET / View / Appearance
This menu item opens the Appearance window. It determines the
appearance of the chromatogram and consists of four tabs:
Chromatogram axes Scaling of chromatogram axes.
Labels Settings for peak labels and baseline
drawing.
Select channel Select channels to be displayed (only
available for multi-channel chroma-
tograms).
Colors Color settings for chromatogram elements.
The appearance settings for a chromatogram are not saved
automatically on closing the chromatogram. In order to have the
same appearance after reopening the chromatogram, it must be
saved explicitly after modification of these parameters with IC
NET / File / Save / Chromatogram
.
Chromatogram axes
Tab
Chromatogram axes
of the
Appearance
window with parame-
ters for scaling of the chromatogram axes.
Time axis
X from Beginning of the window on X axis.
X to End of the window on X axis.
X units Selection of unit ( Retention unit ) for X axis.
