Publication 2711P-QS001A-EN-P - October 2007

93

Qualify the Runtime Application Chapter 7

Reviewing Diagnostic Lists

On your development computer, FactoryTalk View ME software
features a diagnostic list at the bottom of the application window. You
can configure FactoryTalk diagnostics to display information,
warnings, and errors during application development and runtime
operation.

When you test run your application, the diagnostic list displays
messages and errors logged by the application. Use this list to identify
the graphic objects or features that generated the messages or errors.
Correct these errors during the validation process.

The diagnostic lists lets you Clear one or all messages in the list.

Click the Clear button to delete the message that is displayed. If
you resize the list to display more than one message, select a
message and then click Clear.

Click the Clear All button to delete all messages in the list.

To view this diagnostic information during runtime, use either the

default [DIAGNOSTICS] graphic display

or diagnostic list object in a customized graphic display.

TIP

The [DIAGNOSTICS] display is in the Libraries editor
of the application Explorer window if not already
included in your application displays. Import the
[DIAGNOSTIC] display if you are going to use it.
