Page 18
18
Publication 2711P-QS001A-EN-P - October 2007
Chapter 2 Select a Terminal Replacement
Installing a PanelView Plus
Terminal
Install the selected PanelView Plus 1250 or 1500 terminal into the
existing PanelView 1000e or 1400e panel cutout. You may need an
adapter plate depending on your terminal selection.
To assist you with the installation, refer to:
•
PanelView Plus Terminals and Display Modules Installation
Instructions, publication
•
Appropriate adapter plate installation instructions, if required.
