36 Publication 2711P-QS001A-EN-P - October 2007
Chapter 5 Review Object Mapping
Multistate Indicators Multistate Indicators
Numeric Display Numeric Display
Screen Print Button Screen Print Button
Time Display Time and Date Display Set to show time only.
Date Display Time and Date Display Set to show date only.
Alarm History
Sort By Time/Sort By Value Sort Alarms Button
Alarm Status Reset Qty/Time Button Reset Alarm Status Button
Alarm Panel Alarm Banner
Single Line Alarm Window Alarm Banner
Alarm Status Screen Alarm Status List
Local Messages Local Messages
Information Messages Information Messages
Bar Graphs Bar Graphs
Trend Trend
Text Text
Drawing Objects Drawing Objects
ISA Symbols ISA Symbols
Bitmaps, DXF Images Bitmaps, DXF Images
Digital and String Tag Types Bit and String Tag Types
Supported Analog Tag Types:
•
Unsigned Integer
•
Integer
•
Long Integer
•
Floating Point
•
Byte
•
3-BCD, 4-BCD, 8-BCD
Supported Analog Tag Types:
•
Unsigned Integer
•
Integer
•
Long Integer
•
Floating Point
•
Byte
•
3-BCD, 4-BCD
Supported communication:
•
DH Plus
•
Remote I/O multirack
•
ControlNet
Supported communications:
•
DH Plus
•
Remote I/O multirack
•
ControlNet
File transfers occur over DH+ or
ControlNet networks. File transfers occur over DH+ or ControlNet
networks. No bridging network protocols.
File transfers use a memory card. File transfers use a CompactFlash card.
Mapping Objects Between PanelBuilder 1400e and FactoryTalk View ME Software
This PanelBuilder 1400e object Maps to this FactoryTalk View ME object Explanation
