Publication 2711P-QS001A-EN-P - October 2007 35
Review Object Mapping Chapter 5
Reviewing Object Mapping This table identifies PanelBuilder 1400e graphic objects that migrate
into a FactoryTalk View ME application.
IMPORTANT
It is important that you verify the function of all objects after
importing your application to FactoryTalk View ME software.
New objects may not function as expected.
Mapping Objects Between PanelBuilder 1400e and FactoryTalk View ME Software
This PanelBuilder 1400e object Maps to this FactoryTalk View ME object Explanation
Increment Value Button Ramp Button
Decrement Value Button Ramp Button
Increment Value Button with Display Ramp Button and Numeric Display
Decrement Value Button with Display Ramp Button and Numeric Display
Small and Large ASCII Input String Input Enable
Arc with Fill Style set to Solid ME Arc and ME Line The PanelBuilder 1400e object is a closed
shape; the View ME object is not closed
between the arc of two points.
Screen List Selector Screen List Selector
Screen List Selector Enter Button Enter List Key
Screen List Selector
Down Cursor Button Move Down List Key
Screen List Selector
Up Cursor Button Move Up List Key
Control List Selector Control List Selector
Control List Selector Enter Button Enter List Key
Control List Selector
Down Cursor Button Move Down List Key
Control List Selector
Up Cursor Button Move Up List Key
Small and Large Screen
Select Keypad Display List Selector You will need to configure this object to
change to the appropriate displays.
Screen Keypad Enable Display List Selector You will need to configure this object to
change to the appropriate displays.
Goto Screen Button Goto Display Button
Return to Previous Screen Button Return to Display Button
ASCII Display String Display
Numeric Keypad Enable Button Numeric Input Enable Button
Normally Open
Momentary Push Button Momentary Push Button
Normally Closed
Momentary Push Button Momentary Push Button
