16 Publication 2711P-QS001A-EN-P - October 2007
Chapter 2 Select a Terminal Replacement
Selecting a Terminal
Replacement Replacement options for the PanelView 1000e and 1400e terminals
include the PanelView Plus or PanelView Plus CE 1250 and 1500
terminals. Some of the PanelView Plus terminals fit directly into the
existing panel cutout of the PanelView ‘e’ terminals; others will
require an adapter plate.
PanelView Plus Replacement Terminals
For this PanelView ‘e’ terminal Select one of these replacement terminals Adapter Plate
Required Adapter Plate
Cat. No.
PanelView 1000e touch screen PanelView Plus 1250 touch screen
PanelView Plus CE 1250 touch screen
(1)
No —
PanelView 1000e keypad PanelView Plus 1250 keypad or keypad and touch
PanelView Plus CE 1250 keypad or keypad and touch
(1)
No —
PanelView 1400e touch screen PanelView Plus 1250 touch screen
PanelView Plus CE 1250 touch screen
(1)
Yes
2711P-RAT12E
PanelView Plus 1500 touch screen
PanelView Plus CE 1500 touch screen
(1)
Yes
(2) 2711P-RAT15
PanelView 1400e keypad PanelView Plus 1250 keypad or keypad and touch
PanelView Plus CE 1250 keypad or keypad and touch
(1)
Yes 2711P-RAK12E
PanelView Plus 1500 keypad or keypad and touch
PanelView Plus CE 1500 keypad or keypad and touch
(1)
Yes
(2) 2711P-RAK15
(1) The PanelView Plus CE terminal is required if your application requires the set bit cursor point function.
(2) The PanelView Plus or PanelView Plus CE 1500 terminal will fit in the existing PanelView 1400e panel cutout. The adapter plate is required only to cover the stud
mounting holes.
