Rockwell Automation Migrating PanelView Enhanced Terminal Applications - Manual (Page 30)

30 Publication 2711P-QS001A-EN-P - October 2007
Chapter 4 Review the Application Conversion Log
Date labels not supported on Trend's
X-Axis.
at on
.TrendA trend has one or more of its minimum, median or maximum
date labels enabled.The FactoryTalk View ME trend displays the current date in its
title. It does not display the minimum, median or maximum
date as part of its X-axis.Blinking pens not supported by Trend.
at on
.TrendA trend had one or more of its pens configured to blink. The FactoryTalk View ME trend does not allow any of its pens
to blink.Background screen plotting of pens
using expressions not supported by
Trend.
at on
.TrendA trend has one of its pens configured to use background
screen plotting and has an expression assigned to the Pen
Value control.The FactoryTalk View ME trend supports background screen
plotting by adding the tags assigned to the Pen1 to Pen8
controls to a Data Log Model.You cannot add expressions to a Data Log Model.Cursor List object at
on
not supported. Cursor ListA display contains a Cursor List object.FactoryTalk View ME software does not support a Cursor List
object so does not convert it. See page 68 for a workaround.Multistate Indicator Object List at
on
not supported.Multistate Indicator Object List A display contains a Multistate Indicator Object List. FactoryTalk View ME software does not support a Multistate
Indicator Object List so does not convert it. See page 56 for a
workaround.Local Message Object List at
on
not supported.Local Message Object List.A display contained a Local Message Object List.FactoryTalk View ME software does not support a Local
Message Object List so does not convert it. See page 60 for a
workaround.Numeric Data Display Object List at
on
not supported. Numeric Data Display Object
ListA display contains a Numeric Data Display Object List.FactoryTalk View ME software does not support a Numeric
Data Display Object List so does not convert it. See page 64 for
a workaround.Multi-Line Alarm Window blinking
not supported by [ALARM] display.Alarm ConfigurationThe Alarm Message Window is enabled with:•Multi-line set.•Blink enabled.The multiline Alarm Window is converted to a FactoryTalk
View ME software [ALARM] display containing an Alarm List
object.Conversion Log MessagesMessageApplies to this
