Chapter 5
The Develop Menu
5 – 40
Communications via RS–485
Figure 5.19
Test Message Selections pop-up window (for RS-485 communications)
If communicating via RS–485, the Address Selections pop-up window will
open.
Select the DL40 address; then press [
↵
] . If you need to change your
computer’s communications port parameters, highlight Configure Port , and
press [
↵
] . Select COM1 or COM2; press [
↵
] . The
Configure Port window
will open. Set Computer Address and Baud Rate . Note: To change Parity
or Data Bits , return to Ports menu.
Highlight Download (filename ) and press [
↵
] . After file is downloaded,
you will return to the Verify window. Highlight Test Message(s) on DL40 ;
press [
↵
] .
The Message Selections window will open. Highlight number of the message
you want to display and press
[
↵
] . Answer Yes to Start testing messages
now? Message will be displayed on DL40. Press [ESC] to end an
Autorepeat message.
