Rockwell Automation 2706-ND1 DL40 OFFLINE PROGRAMMING SFTWR.USER MANUAL User Manual
Page 65
Chapter 5
The Develop Menu
5 – 20
When you press
[F10]
to accept your Message Picks, the Renumber Message
confirmation pop-up will appear. Use the arrow keys to highlight your choice
and press
[
↵
]
.
Figure 5.12
Renumber (Messages) screen showing Message Selections/Message Picks and other pop-ups
Start/Increment
pop-up window
You may use the following special keys on this screen.
← →
Moves the Message Select cursor to the Message Selections or Message
Picks column
↑
↓
Moves the Message Select cursor up or down within a column
↵
Moves the highlighted message number from one column to the other
Get Online Help
Accept message picks
Closes the Message Selections/Message Picks pop-up without taking
action
Notes
To select a block of messages, move the cursor to the first message on the
block and press
[CTRL][B]
to mark the beginning of the block. Then move
the cursor to the last message in the block and press
[
↵
]
. The entire block
will be moved to the opposite column.
