Chapter 6
The Transfer Menu
6 – 13
!
ATTENTION: Before the upload begins, you will see one of the
following warnings. Which one you see depends on the type and
access settings of your DH+ or Ethernet hardware device.
WARNING: Incorrect address selection could corrupt data in
a non-DL40 device. Verify that the correct Communication
File is selected.
WARNING: Incorrect address selection could corrupt data in
a non-DL40 device. Verify that the correct Communication
File is selected.
DH+ Network Access is set to Local.
WARNING: Incorrect address selection could corrupt data in
a non-DL40 device. Verify that the correct Communication
File is selected.
DH+ Network Access is set to Remote (Bridge)
– Local Address is __.
– Remote Bridge Address is __.
Be sure the selected communication file has the correct
address parameters, and change them if necessary before
continuing.
To specify a new Communication File, highlight Create Communication
File (in either the Download (Remote I/O) or Upload (Remote I/O) menus)
and press [
↵
] . You will be asked to specify a file name. To create a file in
another directory, highlight Directory and press [
↵
] and the Program Data
directory window will open. Enter the directory in the form:
Drive:\Root\Subdir
Press [
↵
] . The Communication File window will open. Highlight the
parameter you want to set and press [
↵
] . Select parameter setting and press
[
↵
] . When you highlight Hardware Device and press [
↵
] , a pop-up
window will open from which you can select the hardware device you are
using. Set device parameters.
Creating a New
Communications File
