Rockwell Automation 2706-ND1 DL40 OFFLINE PROGRAMMING SFTWR.USER MANUAL User Manual
Page 77
Chapter 5
The Develop Menu
5 – 32
Figure 5.15
Message Attribute Default screen
Special keys
You can use the following special keys on this screen.
↑
↓
Moves the cursor up or down the attribute list
↵
Lists or accepts attribute choices
Moves cursor to first attribute
Moves cursor directly to Quit
Get Online Help
Closes the Message Attribute Defaults window without taking action.
Notes
Refer to the previous section for descriptions of each message attribute.
If
Line Usage
is other than
All Lines
, then the display line on the DL40
does not necessarily correspond to the cursor row value shown on the
message editing window during editing.
