Page 54
Chapter 5
The Develop Menu
5 – 9
Special keys
You may use the following special keys on this menu.
↓
↑
Move the cursor to the desired function
Move the cursor directly to the first menu item
Move the cursor directly to the last menu item (
Quit)
↵
Selects the item highlighted by the cursor
Closes the Develop menu and returns cursor to Main menu
Get Online Help
After you have selected
Edit Message
, the Message Selections pop-up
window shown in Figure 5.7 will open on the screen. Select the message you
want to edit, then press
[
↵
]
to open the Message Text window shown in
Figure 5.8.
Figure 5.7
Message Selections pop-up, which appears after you select Edit Message
Edit Message Screen
