Title screen & main menu bar – Rockwell Automation 2706-ND1 DL40 OFFLINE PROGRAMMING SFTWR.USER MANUAL User Manual
Page 39
Chapter 4
Navigating the Software
4 – 2
The program opens with the Title screen shown in Figure 4.1. The screen
identifies the product, and indicates the revision number and date of that
copy of the software. You can close this screen and open the Main Screen
(shown in Figure 4.2) by pressing any key.
Figure 4.1
Opening screen
Figure 4.2
Main screen
Cursor
Menu Bar
Date & Time
Menu Title
Menu Choice
Title Screen & Main Menu Bar
