Chapter 5
The Develop Menu
5 – 3
When Select File is selected, a window will appear with the default path in
the upper left corner and a list of the files found in that path. If you want to
edit files under a different path, press
[ESC] , highlight Directory , and press
[
↵
] . You can then edit the program’s data path in the pop-up window shown
in Figure 5.4.
Figure 5.2
File Selections screen showing typical application file list
Path
Time file was created
or last edited
Date file was created or
last edited
File length in bytes
Special keys
You may use the following special keys on the File Selections screen.
↓ ↑
Move the cursor to the desired file
Move the cursor directly to the first file
Move the cursor directly to the last file
↵ Selects the item highlighted by the cursor (Goes to Develop Screen
illustrated in Figure 5.5)
Returns to the top level of the Develop menu
Get Online Help
File Selections Screen
