Chapter 5
The Develop Menu
5 – 10
Special keys
You may use the following special keys on this pop-up.
↑ ↓
Moves the cursor to the desired message
Moves cursor directly to the first m essage
Moves cursor directly to the last message
↵ Selects the message highlighted by the cursor and opens the Message
text window
Closes the pop-up and returns to the Messages menu
Get Online Help
After you have selected a message from the Message Selections pop-up
window by highlighting it and pressing
[
↵
] , a window will open showing the
text of the selected message. In this window you can edit the message as
required.
Note that the Message Text window also appears when you select Create
New Message from the Messages menu as described on page 5 – 15.
Figure 5.8
Message Text window
Message Text Cursor
Messages can contain up to
20 characters (including
spaces) per line.
Insert or Overstrike Mode
Column cursor is currently in
Row cursor is currently in. Note that the cursor row does not
necessarily correspond to the display line on the DL40 if Line
Usage is other than All Lines. See discussion of Attributes.
Message Text Window
