Chapter 7
The Reports Menu
7 – 4
Parameter Acceptable values
Null Count 0
Page Width 20 to 132
Figure 7.3
Configure Ports menus
COM Port
Configuration
LPT Port
Configuration
The parameters for COM ports include:
Parameter Acceptable values
Null Count 0
Page Width 20 to 132
Baud 110. 150, 300, 600, 1200, 2400, 4800, 9600
Parity None, Odd, Even
Data Bits 7 bits, 8 bits
Stop Bits 1 bit, 2 bits
Handshake None, Software, Hardware
When the settings on the Configure Port window meet your needs, press
[END] or use the down arrow key to move to the last line of the window and
highlight Quit . Press [
↵
] to close the Configure Port window and return to
the Select File menu.
Check to make sure your printer is properly connected and turned ON. Move
the cursor to the
Print FILENAME line on the Select File menu and press
[
↵
] .
Starting the Print Job
