Rockwell Automation 2706-ND1 DL40 OFFLINE PROGRAMMING SFTWR.USER MANUAL User Manual
Page 106
Chapter 6
The Transfer Menu
6 – 18
Figure 6.13
Ethernet Parameters configuration screen
Parameter
Acceptable values
Routing
PLC 5E
5130-RM
5130-KA
Pushwheel
1 to 8
Channel
2
3
Routing
The
Routing
value will most often be set to a PCL 5E, which indicates that
the Remote I/O link is attached directly to the PLC being addressed. Choose
the 5130-KA or 5130-RM selections if your are performing transfers via a
PLC-5/250 in a Pyramid Integrator chassis.
Pushwheel
A
Pushwheel
must be specified when the 5130-KA module has been
selected in the
Routing
field. This value should match the configuration of
the PLC-5/250.
Channel
You need to specify a
Channel
if you select either a 5130-KA or 5130-RM
module. The value in this field should be either 2 or 3 as previously selected
on the PLC-5/250.
After all parameters are set, highlight
Quit
and press
[
↵
]
.
