Page 44
Chapter 4
Navigating the Software
4 – 7
Use the following keystrokes to navigate the Offline Programming Software
menus. These keys have the same effect wherever they are used in the
software. Individual screens may use additional keystroke commands. Those
additional commands will be described immediately below the sample
screens that appear throughout this manual.
Help. Pressing F1 when Help is open will open the Menu Key Control help
screen
Toggle Help screen between partial and full screen view.
Return to the previous menu.
↵
Select highlighted menu item.
↑
Highlight previous menu item.
↓
Highlight next menu item
→
Move the cursor to the right
←
Move the cursor to the left
Highlight first menu item.
Highlight last menu item.
You can also select most menu items by typing their initial letter. For
example, to exit the program you can type
[E][Y]
.
[E]
is the initial letter in
the
Exit
Main menu item, and
[Y]
is the initial letter of the
Yes
Exit menu
item.
Menu Key Control
Shortcut Keys
