Chapter 5
The Develop Menu
5 – 19
Special keys
You may use the following special keys on this screen.
← → Moves the Message Select cursor to the Message Selections or Message
Picks column
↑ ↓
Moves the Message Select cursor up or down within a column
↵
Moves the highlighted message number from one column to the other
Get Online Help
Accept message picks
Closes the Message Selections/Message Picks pop-up without taking
action
Notes
To select a block of messages, move the cursor to the first message on the
block and press
[CTRL][B] to mark the beginning of the block. Then move
the cursor to the last message in the block and press [
↵
] . The entire block
will be moved to the opposite column.
When you select Delete from the Messages menu, the Message
Selections/Message Picks pop-up window opens. All message numbers in the
current file will appear in the Message Selections column. To move a
message from the Message Selections column to the Message Picks column,
press
[
↵
] .
After you have moved all the messages to be renumbered into the Message
Picks column, press
[F10] and the Start/Increment pop-up window will
appear. When it does, press [
↵
] to open the Starting Message Location field.
Input the new message number you want to assign to the first message on
your list. Insert a value in the Increment field if you are renumbering
multiple messages.
For example, suppose you want to renumber message numbers 1, 2, and 3 to
a starting number of 10 and an increment of 5. As a result:
Message 1 would become message number 10.
Message 2 would become message number 15.
Message 3 would become message number 20.
Renumber (Messages)
Screen
