Rockwell Automation Publication 1756-UM533C-EN-P - February 2011 25
Chapter
2
Module Installation
Introduction The 1756-IF8H, 1756-OF8H, and 1756-IF16H analog modules use the HART
protocol with eight and 16 channels, respectively. This chapter describes basic
installation procedures.
The table explains the topics discussed in this chapter.
Topic Page
Environment and Enclosure 26
Preventing Electrostatic Discharge 26
European Hazardous Location Approval 26
North American Hazardous Location Approval 27
Removal and Insertion Under Power (RIUP) 28
Before You Begin 28
Module Accessories 28
Power Requirements 29
Install the Module 30
Key the Removable Terminal Block/Interface Module 31
Wire the Removable Terminal Block 32
Ground the Module 32
Wire the Module 34
Removal Terminal Block Assembly and Installation 34
Remove the Removable Terminal Block 36
Remove the Module 37
