Rockwell Automation Publication 1756-UM533C-EN-P - February 2011 181
Tag Definitions Appendix A
Module-defined Data
Types, 1756-OF8H Module These tables describe module-defined data types for the 1756-OF8H module
and include information for configuration, input, and output tags.
Configuration
This table describes the configuration tags available in the 1756-OF8H module.
Table 66 - Configuration (AB:1756_OF8H:C:0)
Member Name Type Style Description
ProgToFaultEN BOOL Decimal
Ch0Config AB:1756_OF8H_ChConfig_Struct:C:0
RampToFault BOOL Decimal ConfigBits:9.
RampToProg BOOL Decimal ConfigBits:8.
RampToRun BOOL Decimal ConfigBits:7.
ProgMode BOOL Decimal ConfigBits:6.
FaultMode BOOL Decimal ConfigBits:5.
LimitAlarmLatch BOOL Decimal ConfigBits:4.
RampAlarmLatch BOOL Decimal ConfigBits:3.
AlarmDisable BOOL Decimal ConfigBits:2.
HoldForInit BOOL Decimal ConfigBits:1.
HARTEn BOOL Decimal ConfigBits:0, HART enabled.
RangeType INT Decimal 0 = 0…20 mA
1 = 4…20 mA
MaxRampRate REAL Float Time constant of low pass filter in ms. See Digital Filter on page 71 for more information.
FaultValue REAL Float
ProgValue REAL Float
LowSignal REAL Float Lower current value for scaling to engineering units. Default is 4 mA. Must be less than HighSignal
and more than minimum input range. See
Scaling to Engineering Units on page 98 for more
information.
HighSignal REAL Float Upper current value for scaling to engineering units. Default is 10 mA. Must be more than LowSignal
and less than maximum input range. See
Scaling to Engineering Units on page 98 for more
information.
LowEngineering REAL Float Measured quantity in engineering units that results in a signal level equal to LowSignal. See Scaling
to Engineering Units on page 98 for more information.
HighEngineering REAL Float Measured quantity in engineering units that results in a signal level equal to HighSignal. See Scaling
to Engineering Units on page 98 for more information.
LowLimit REAL Float Output signal will be clamped at this value in engineering units even if Ch0Data is lower than this.
HighLimit REAL Float Output signal will be clamped at this value in engineering units if Ch0Data is larger than this.
CalBias REAL Float Sensor offset in engineering units added to the measured signal before reporting Ch0.Data.
Ch1Config AB:1756_OF8H_ChConfig_Struct:C:0
Ch2Config AB:1756_OF8H_ChConfig_Struct:C:0
Ch3Config AB:1756_OF8H_ChConfig_Struct:C:0
Ch4Config AB:1756_OF8H_ChConfig_Struct:C:0
