188 Rockwell Automation Publication 1756-UM533C-EN-P - February 2011
Appendix A Tag Definitions
PowerLow BOOL Decimal Low power.
PV REAL Float Primary value. This is the same value as signaled on the analog channel and is the most important
measurement made by this device.
SV REAL Float Secondary value.
TV REAL Float Third value.
FV REAL Float Fourth value.
PVStatus SINT Hex Primary status.
16#C0 = Connected.
16#00 = Not Connected.
SVStatus SINT Hex Secondary status.
16#C0 = Connected.
16#00 = Not Connected.
TVStatus SINT Hex Third status.
16#C0 = Connected.
16#00 = Not Connected.
FVStatus SINT Hex Fourth status.
16#C0 = Connected.
16#00 = Not Connected.
Ch1 AB:1756_OF8H_HARTDataAll_Struct:I:0, Channel 01 analog and HART data.
Ch2 AB:1756_OF8H_HARTDataAll_Struct:I:0, Channel 02 analog and HART data.
Ch3 AB:1756_OF8H_HARTDataAll_Struct:I:0, Channel 03 analog and HART data.
Ch4 AB:1756_OF8H_HARTDataAll_Struct:I:0, Channel 04 analog and HART data.
Ch5 AB:1756_OF8H_HARTDataAll_Struct:I:0, Channel 05 analog and HART data.
Ch6 AB:1756_OF8H_HARTDataAll_Struct:I:0, Channel 06 analog and HART data.
Ch7 AB:1756_OF8H_HARTDataAll_Struct:I:0, Channel 07 analog and HART data.
CSTTimestamp DINT[2] Hex Coordinated system time.
RollingTimestamp INT Decimal 15-bit time from power on/reset in milliseconds.
Table 69 - Analog and HART by Channel (AB:1756-OF8H_AnalogHARTbyChannel:I:0)
Member Name Type Style Description
