Rockwell Automation Publication 1756-UM533C-EN-P - February 2011 199
Additional HART Protocol Information Appendix C
36 Set upper-
range value (=
push SPAN
button) None None
37 Set lower-
range value (=
push ZERO
button)
38 Reset
‘configuration
changed’ flag
39 EEPROM
control 0 EEPROM control
code
(3)
As in command
40 Enter/exit
Fixed Current
mode 0…3
(1)
Current (mA) (F) As in command
41 Perform device
self-test None None
42 Perform
master reset
43 Set (trim) PV
zero
44 Write PV units 0 PV units code As in command
45 Trim DAC zero 0…3 Measured current
(mA)
46 Trim DAC gain 0…3 (F)
47 Write transfer
function 0 Transfer function
code
48 Read
additional
device status Moved to Universal
Commands in HART
version 7. See 48 in Universal Commands
49 Write PV
sensor serial
number 0…2 Sensor serial
number As in command
50 Read dynamic
variable
assignments None 0
1
2
3 PV transmitter variable code
SV transmitter variable code
TV transmitter variable code
FV transmitter variable code x
x
x
x
51 Write dynamic
variable
assignments 0
1
2
3
PV transmitter
variable code
SV transmitter
variable code
TV transmitter
variable code
FV transmitter
variable code As in command
52 Set transmitter
variable zero 0 Transmitter variable
code
53 Write
transmitter
variable units Transmitter variable
code
Table 76 - Common Practice Commands
Command Data in Command Data in Reply Contained in
No. Function Byte Data Type
(6)
Byte Data Type
(6)
Input
Tag CIP
MSG
