Appendix B Use 1492 Wiring Systems with Your Analog I/O Module
The table lists the AIFMs and pre-wired cables that can be used with the
1756-IF8H, 1756-IF16H, and 1756-OF8H modules.
IMPORTANT
For the latest list, see the Digital/Analog Programmable Controller
Wiring Systems Technical Data, publication
Table 71 - Analog Interface Module and Pre-wired Cables
I/O Cat. No. Mode
AIFM Cat. No.
(Fixed Terminal
Block)
AIFM Cat. No.
(RTB Socket
Assembly)
AIFM Type
Description
Pre-wired Cable
(2)
(x=cable length)
1756-IF8H
Current
1492-AIFM8-3
1492-RAIFM8-3
(1)
Feed-
through
8-channel input or output
with 3 terminals/channel
1492-ACABLExUD
1492-AIFM8-F-5
N/A
Fused
8-channel input with 24V DC
BF indicators and
5 terminals/channel
Voltage
1492-AIFM8-3
1492-RAIFM8-3
(1)
Feed-
through
8-channel input or output
with 3 terminals/channel
1492-ACABLExUC
1492-AIFM8-F-5
N/A
Fused
8-channel input with 24V DC
BF indicators and
5 terminals/channel
1756-IF16H
Single-ended
Current
1492-AIFM16-F-3 N/A
Fused
16-channel input with 24V
DC BF indicators and
3 terminals/channel
1492-ACABLExUB
1756-OF8H
Current
1492-AIFM8-3
1492-RAIFM-8-3
(1)
Feed-
through
8-channel input or output
with 3 terminals/channel
1492-ACABLExWB
Voltage
1492-ACABLExWA
(1) C
o
mpatible RTB plug; 1492-RTB8N (screw-style terminals) or 1492-RTB8P (push-in style terminals). Order plugs separately.
(2) Cables are available in lengths of 0.5 m, 1.0 m, 2.5 m, and 5.0 m. To order, insert the code for the desired cable length into the catalog number in place of the x: 005=0.5 m,
010=1.0 m, 025=2.5 m, 050=5 m. Example: 1492-ACABLE025TB is for a 2.5 m cable, and the letters TB.
Table 72 - I/O module-ready Pre-wired cables
Cat. No.
(1)
Number of
Conductors
(2)
(3)
Conductor
Size
Nominal Outer
Diameter
Removable
Terminal Block at
the I/O Module End
1492-ACABLExUB
20 conductors
22 AWG
8.4 mm (0.33 in.)
1756-TBCH
1492-ACABLExUC
9 twisted pairs
6.8 mm (0.27 in.)
1492-ACABLExUD
1492-ACABLExWA
1756-TBNH
1492-ACABLExWB
(1) Cables are available in lengths of 0.5 m, 1.0 m, 2.5 m, and 5.0 m. To order, insert the code for the desired cable
length into the catalog number in place of the x: 005=0.5 m, 010=1.0 m, 025=2.5 m, 050=5 m. Example: 1492-
ACABLE025TB is for a 2.5 m cable, and the letters TB.
(2) Each cable for analog I/O has an overall shield with a ring lug on a 200 mm (8.87 in.) exposed drain wire at the
I/O module end of the cable.
(3) Not every connection is always used.
