Rockwell Automation 1756-OF8H ControlLogix HART Analog I/O Modules User Manual
Page 162
162
Rockwell Automation Publication 1756-UM533C-EN-P - February 2011
Chapter 11
Module Troubleshooting
Table 53 - 1756-IF16H Channel Level Error Codes
Channel x Extended Status = Channel 0 Error Value + (x *16)
Channel
Channel Status
0
1
2
3
4
5
6
7
Exte
nded Fault Codes
16#0007
16#0017
16#0027
16#0037
16#0047
16#0057
16#0067
16#0077
Invalid Input Range
16#0008
16#0018
16#0028
16#0038
16#0048
16#0058
16#0068
16#0078
Invalid Digital Filter
16#000A
16#001A
16#002A
16#003A
16#004A
16#005A
16#006A
16#007A
High Signal and/or Low Signal outside of
selected input range
16#000B
16#001B
16#002B
16#003B
16#004B
16#005B
16#006B
16#007B
High Signal
≤ Low Signal
16#000C
16#001C
16#002C
16#003C
16#004C
16#005C
16#006C
16#007C
Sensor Offset set to NaN.
16#000D
16#001D
16#002D
16#003D
16#004D
16#005D
16#006D
16#007D
High Engineering = Low Engneering
Channel (cont.)
8
9
10
11
12
13
14
15
Ex
tended Fault
Codes
16#0087
16#0097
16#00A7
16#00B7
16#00C7
16#00D7
16#00E7
16#00F7
Invalid Input Range
16#0088
16#0098
16#00A8
16#00B8
16#00C8
16#00D8
16#00E8
16#00F8
Invalid Digital Filter
16#008A
16#009A
16#00AA
16#00BA
16#00CA
16#00DA
16#00EA
16#00FA
High Signal and/or Low Signal outside of
selected input range
16#008B
16#009B
16#00AB
16#00BB
16#00CB
16#00DB
16#00EB
16#00FB
High Signal
≤ Low Signal
16#008C
16#009C
16#00AC
16#00BC
16#00CC
16#00DC
16#00EC
16#00FC
Sensor Offset set to NaN.
16#008D
16#009D
16#00AD
16#00BD
16#00CD
16#00DD
16#00ED
16#00FD
High Engineering = Low Engneering
Table 54 - 1756-OF8H Channel Level Error Codes
Channel x Extended Status = Channel 0 Error Value + (x *22)
Channel
Channel Status
0
1
2
3
4
5
6
7
Additional Fa
ult Codes
16#0005
16#001B
16#0031
16#0047
16#005D
16#0073
16#0089
16#009F
Bad Ramp Latch
16#0006
16#001C
16#0032
16#0048
16#005E
16#0074
16#008A
16#00A0
Bad Clamp Latch
16#000A
16#0020
16#0036
16#004C
16#0062
16#0078
16#008E
16#00A4
Bad Ramp to Idle
16#000B
16#0021
16#0037
16#004D
16#0063
16#0079
16#008F
16#00A5
Bad Ramp to Fault
16#000C
16#0022
16#0038
16#004E
16#0064
16#007A
16#0090
16#00A6
Invalid Input Range
16#000D
16#0023
16#0039
16#004F
16#0065
16#007B
16#0091
16#00A7
Bad Max Ramp
16#000E
16#0024
16#003A
16#0050
16#0066
16#007C
16#0092
16#00A8
Bad Fault Value
16#000F
16#0025
16#003B
16#0051
16#0067
16#007D
16#0093
16#00A9
Bad Idle Value
16#0010
16#0026
16#003C
16#0052
16#0068
16#007E
16#0094
16#00AA
Signal Out of Range
16#0011
16#0027
16#003D
16#0053
16#0069
16#007F
16#0095
16#00AB
Low Signal Greater or Equal to High Signal
16#0012
16#0028
16#003E
16#0054
16#006A
16#0080
16#0096
16#00AC
Sensor Offset set to NaN
16#0013
16#0029
16#003F
16#0055
16#006B
16#0081
16#0097
16#00AD
High Engineering Equal to Low Engineering
16#0014
16#002A
16#0040
16#0056
16#006C
16#0082
16#0098
16#00AE
Invalid HART Rate
16#0015
16#002B
16#0041
16#0057
16#006D
16#0083
16#0099
16#00AF
Bad Clamp
