5-26 Configuration and Programming
Active Device Status
Word 10 provides active device status for primary/normal devices.
When a RIO device is communicating with the scanner the bit
corresponding to the device’s logical starting group is set to 1.
Devices that are inhibited in the M0 file (M0:e.8 - M0:e.11) are
represented by a 0. Unless devices are inhibited, not responding to
communications, or configured to an incorrect logical rack size, this
word is identical to the device configuration (M1:e.8).
Word 5 provides active device status for complementary devices.
When a RIO device is communicating with the scanner the bit
corresponding to the device’s logical starting group is set to 1.
Devices that are inhibited in the M0 file are represented by a 0. Unless
devices are inhibited, not responding to communications, or
configured to an incorrect logical rack size, this word is identical to
the device configuration (M1:e.3).
0
0
2
4
6
0
2
4
6
0
2
4
6
0
2
4
6
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
1
0
0
1
0
0
0
0
1
0
0
0
1
0
0
1
0
1
1
1
1
1
0
1
1
0
0
1
1
1
1
0
0
1
1
0
0
0
0
1
0
0
0
0
0
0
M1 (Status) File-Word 10
A 0 indicates that the device is inhibited, not
responding to communications, or configured
to an incorrect logical rack size.
A 1 indicates that the configured device is active.
RIO Rack 3
Starting Group
RIO Rack 2
Starting Group
RIO Rack 1
Starting Group
RIO Rack 0
Starting Group
Primary Logical Device Address, Word 8
Primary Logical Image Size, Word 9
Primary Active Device Status, Word 10
M1 File
M1:e.8
M1:e.9
M1:e.10
Bit Number (decimal)
IMPORTANT
When a primary device is inhibited, its
complementary device is also inhibited. A
complementary device cannot be exclusively
inhibited.
0
0
2
4
6
0
2
4
6
0
2
4
6
0
2
4
6
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
1
0
0
1
0
0
0
0
1
0
0
0
1
0
0
1
0
1
1
1
1
1
0
1
1
0
0
1
1
1
1
0
0
1
1
0
0
0
0
1
0
0
0
0
0
0
M1 (Status) File-Word 5
A 0 indicates that the device is inhibited not responding to
communications, or configured to an incorrect logical rack size.
A 1 indicates that the configured device is active.
RIO Rack 11
Starting Group
RIO Rack 10
Starting Group
RIO Rack 9
Starting Group
RIO Rack 8
Starting Group
Primary Logical Device Address, Word 3
Primary Logical Image Size, Word 4
Primary Active Device Status, Word 5
M1 File
M1:e.3
M1:e.4
M1:e.5
Bit Number (decimal)
