5-2 Configuration and Programming
The 1747-BSN module’s I/O image structure is described below:
•
The I/O image file consists of four logical racks (numbered 0, 1,
2, and 3) of input image and four logical racks of output image.
•
Each logical rack consists of eight logical groups (numbered 0,
1, 2, 3, 4, 5, 6, and 7).
•
Each logical group consists of two words (an input word and an
output word).
•
Each word consists of two bytes (a high and a low byte). Low
byte is bits 0 through 7 and high byte is bits 8 through 15.
•
Each byte consists of eight bits, with each bit having the ability
