Summary of Changes
The information below summarizes the changes to this manual since
the last printing. To help you find new and updated information in
this release of the manual, we have included change bars as shown to
the right of this paragraph.
The table below lists the pages or sections containing new or revised
information.
For this information: See
clarification of the user identification DIP
switch operation page 3-3
expanded wiring section with simplified
examples for RIO, DH+, and RS-232 network
wiring pages 3-6 through 3-9
G-file configuration using RSLogix 500 pages 5-3 through 5-5
revised ladder logic example for monitoring
the System Status Word and Module Status
Word pages 6-10 through 6-12
new information on using block transfer
instructions (BTR and BTW) pages 7-9 through 7-21
revised ladder logic example for
transferring data table values to the
secondary processor pages 9-2 through 9-13
updated certifications page A-1
