Appendix
Code table
l
426
EDBCSXS064 EN 4.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C7530
Display of the current signal
states on the analog input of the
"Torque" function block
−32768
(= −100 %)
{1}
32767
(= 100 %)
1 TorqueIn−anl
Torque setpoint
(SPEED-MCTRL.MAdd)
^ 354
2 TorqueIn−anl
Setpoint for the upper limit of
speed limitation
(TORQUE−NSET.NSet)
^ 351
3 TorqueIn−anl
Lower torque limit
(TORQUE-MCTRL.negLoMLim)
^ 354
4 TorqueIn−anl
Upper torque limit
(TORQUE-MCTRL.HiMLim)
5 TorqueIn−anl
Setpoint for the lower limit of
speed limitation
(TORQUE−MCTRL.NStartMLim)
6 TorqueIn−anl
Manual field weakening
(TORQUE−MCTRL.FldWeak)
7 TorqueIn−anl
Manual adaptation of the
proportional gain of the speed
controller
(TORQUE−MCTRL.NAdapt)
8 TorqueIn−anl
Manual adaptation of the
integral−action component of the
speed controller
(TORQUE−MCTRL.ISet)
9 TorqueIn−anl
Torque threshold for the motor
holding brake
(TORQUE−BRK.TorqueThreshold)
^ 360
10 TorqueIn−anl
Direction of torque created by
the drive against the motor
holding brake
(TORQUE−BRK.Sign)
