Appendix
Code table
l
364
EDBCSXS064 EN 4.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
[C0006] Op mode
1
Operating mode of the motor
control
l
If the master pulse (via
MCTRL: C0911 = 0 or DfIn:
C0428 = 0) is used, the
voltage supply has to be
switched off and then on
again when the operating
mode is changed.
l
Otherwise, the master pulses
will not be recognised.
1
Servo PM−SM
Servo control of synchronous
motors
2
Servo ASM
Servo control of asynchronous
motors
C0009 LECOM
address
1
Entry of the device address for
operation via AIF interface X1
1
{1}
99 Communication modules on AIF
interface X1:
l
LECOM−A/B/LI 2102
l
PROFIBUS−DP 2133
C0011 Nmax
3000
Maximum speed
500
{1 rpm}
16000 Reference value for the absolute
and relative setpoint selection
for the acceleration and
deceleration times.
For parameter setting via
interface: greater changes in one
step should only be made when
the controller is inhibited (CINH)!
C0012 TIR (ACC)
0.000
Acceleration time for the
l
speed setpoint (for "speed
control")
l
torque setpoint (for "torque
control")
^ 327
0.000
{0.001 s}
999.999 Relating to speed variation
0 rpm ... n
max
(C0011)
C0013 TIF (DEC)
0.000
Deceleration time for the
l
speed setpoint (for "speed
control")
l
torque setpoint (for "torque
control")
^ 327
0.000
{0.001 s}
999.999 Relating to speed variation
0 rpm ... n
max
(C0011)
C0017 FCODE (Qmin)
50
Free code for using speed signals
(Speed signal FCODE_nC17_a)
^ 309
−16000
{1 rpm}
16000
C0018 fchop
2
Switching frequency
1
4 kHz sin
4 kHz permanent PWM
frequency
2
8/4 kHz sin
8 kHz PWM frequency with
automatic derating to 4 kHz at
high load
C0019 Thresh nact =
0
0
Threshold when actual speed
value (n
act
) = 0 is detected.
(DCTRL_bNActEq0_b)
0
{1 rpm}
16000
