Appendix
Code table
l
393
EDBCSXS064 EN 4.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C0595 MONIT CE4
3
Fault response − system bus
(CAN) monitoring "Bus−off" at X4
"BusOffState" (CE4)
^ 198
0
TRIP
2
Warning
3
Off
C0596 NMAX limit
5500
Maximum system speed
^ 223
0
{1 rpm}
16000
C0597 MONIT LP1
3
Fault response − monitoring of
motor phase failure (LP1)
When this function is activated,
the calculating time provided for
the user program is reduced!
^ 217
0
TRIP
2
Warning
3
Off
C0598 MONIT SD5
3
Fault response − master current
monitoring at X6 < 2 mA
"MastISourceDef"
0
TRIP
2
Warning
3
Off
C0599 Limit LP1
5.0
Monitoring limit for motor phase
failure monitoring (LP1) with
regard to the current limit.
^ 217
0.01
{0.01 %}
10.00
C0602 MONIT REL1
3
Fault response − open circuit
monitoring of relay output X25
0
TRIP
2
Message
3
Off
4
FAIL−QSP
C0603 MONIT CE5
3
Fault response − gateway
function monitoring (CE5)
"Timeout" when remote
parameter setting (C0370) is
activated via interface X4 (CAN)
^ 198
^ 190
0
TRIP
2
Warning
3
Off
C0604 MONIT OC7
2
Fault response − monitoring of
Ixt device utilisation.
Ixt threshold can be set under
C0123.
^ 201
0
TRIP
2
Warning
3
Off
