Appendix – Lenze ECSCSxxx User Manual
Page 384

Appendix
Code table
l
384
EDBCSXS064 EN 4.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C0362 Sync cycle
Time interval between 2 sync
telegrams via the X4 CAN bus
interface or EMF2192IB EtherCAT
communication module at X1 AIF
interface
Read only
^ 179
1
{1 ms}
30
C0363 Sync correct.
1
CAN sync correction increment
^ 180
1
0.2
ms/ms
2
0.4
ms/ms
3
0.6
ms/ms
4
0.8
ms/ms
5
1.0
ms/ms
C0365 DIS:CAN
active
Input signal CAN active
Only display
0
CAN not active
1
CAN active
C0366 Sync Response
1
CAN sync response for interface
X4 (CAN)
The value "1" should always be
set!
^ 181
0
No response
1
Response
C0367 Sync Rx ID
128
CAN sync receipt ID for CAN bus
interface X4
^ 180
1
{1}
256
C0368 Sync Tx Id
128
CAN Sync transmission ID for
CAN bus interface X4
^ 444
^ 179
1
{1}
256
C0369 SyNc Tx time
0
CAN sync transmission cycle for
CAN bus interface X4
A sync telegram with the
identifier of C0368 is sent with
the cycle time set.
ECSxP: The setting is effected
automatically depending on
C4062!
^ 180
0
{1 ms}
65000 0 = switched off
[C0370] SDO gateway
0
Activate address
gateway/remote
parameterisation
l
C0370
¹ 0: All code
write/read accesses are
redirected to the CAN node
with the CAN node address
set here.
l
The corresponding code is
accessed via parameter data
channel 1 of the target device.
l
C0370 = 0: remote
parameterisation is
deactivated
^ 190
0
{1}
63
