Function library
DFOUT (master frequency output)
l
305
EDBCSXS064 EN 4.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
[C0540] X8 Signal out
2
Function of the digital frequency
output signals on X8 (DFOUT)
^ 304
^ 103
0
DFOUT in [%]
1
DFOUT in [rpm]
2
Encoder simulation + zero pulse
®
DFOUT
C0545 PH offset
0
Phase offset
^ 304
0
{1 inc}
65535 1 revolution = 65535 increments
C0547 DIS: AN−IN
Analog signal on the input of the
DFOUT block
Read only
^ 304
−199.99
{0.00 %}
199.99
C0549 DIS: DF−IN
Speed on the input of the DFOUT
block
Only display
^ 304
−32767
{1 rpm}
32767
C6430 DFOUT
Display of the analog output
signal DFOut−Out in the DFOUT
function block
^ 304
−32768
{1}
32767
[C6431] DFOUT
1000
Selection of the analog output
signal DFOut−Out for the DFOUT
function block
^ 304
FIXED 0 % (not assigned)
For possible signals see "selection list − analog
signals"
^ 437
