Code table
l
367
EDBCSXS064 EN 4.0
IMPORTANT
Possible settings
Code
Selection
Lenze/
{Appl.}
Designation
No.
C0058 Rotor diff
−90.0
Rotor displacement angle (offset
angle)
Input in case of Lenze motor with
l
resolver: −90°
l
hiperface absolute value
encoder: 0°
Code value is adapted by the
rotor position adjustment
function (C0095).
Only relevant for the operation
of synchronous motors.
^ 151
−180.0
{0.1
_}
179.9
C0059 Mot pole no.
Calculated number of motor pole
pairs
Read only
1
{1}
200
C0060 Rotor pos
Current rotor position; value is
derived from position encoder.
Therefore, it is only valid as rotor
position if the position encoder
settings under C0490 are
identical with the settings of the
speed encoder on the motor
shaft under C0495.
Read only
^ 148
0
{1 inc}
2047 Display with reduced resolution:
1 revolution = 2048 increments
C0061 Heatsink
temp
Heatsink temperature
Read only
^ 204
−200
{1
°C}
200
C0062 Interior temp
Interior device temperature
Read only
^ 205
−200
{1
°C}
200
C0063 Mot temp
Motor temperature
Read only
^ 202
0
{1
°C}
200
C0064 Utilization
Device utilisation (I x t) over the
last 180 s
Only display
0
{1 %}
150
l
C0064 > 100 % activates
OC5−TRIP.
l
TRIP−RESET only is possible if
C0064 < 95 %.
C0065 U24 ext
External low−voltage supply
(U
24
)
Read only
0,0
{0.1V}
100,0
C0066 Motor load
Thermal motor load I
2x
t
Only display
^ 210
0
{1 %}
250
C0067 Act trip
Current fault (TRIP)
(in case of FAIL−QSP, warning and
message, "0" is displayed.)
Only display
^ 238
